Cost-effective solution for nail clip assembly – automatic assemble nail into nylon plug. Various models for single nail, and dual nails. High assembly efficiency. Make assembly be high productivity and quality with minimum labor and space.
Function - It assembles the nail with the plug by the cooperation of the intermittent motion and pneumatic cylinder.
High Performance - One machine for one plug. None adjustment!
Auxiliary - Additional hopper to save labor for filling the parts.
Machine size (L x W x H): 1,850 x 1,250 x 1,950 mm, N.W.: 630 KG, with hopper, without safety cover
Machine size (L x W x H): 2,250 x 1,520 x 2,200 mm, N.W.: 830 KG, with safety conver (SB04/05/06/10)
Machine size (L x W x H): 1,910 x 1,400 x 1,800 mm, N.W.: 750 KG, without safety conver (SB11)
Machine size (L x W x H): 2,100 x 1,320 x 1,910 mm, N.W.: 830 KG, with safety conver (SB13)
OEM, ODM machine. Tool machine according to nail and clip specification, safety cover is optional, hopper is optional. Appearance will be various due to design requirement.
Model
Clip Height
Nali Length
Speed (PPM)
Remark
SB03-13
H < 13 (0.512)
L < 44 (1.732)
50 ~ 70
dual nails, nail distance < 22 (0.866), 3-pc assembly
